Denafrips Iris 12th

Technical Highlights

• Proprietary FPGA DSP Processing Architecture

• FIFO Buffer and Reclock with Internal Crystal

• TCXO Temperature Compensated Crystal Oscillator

• Optical Isolated All Digital Input Interfaces

• Proprietary USB Audio Solution via STM32F446 Advanced AMR Based MCU

• Licensed Thesycon USB Driver For Windows Platform

• Driverless On Mac & Linux

• External Clocks Input Supported

• 60VA UPOCC Copper O-Core Transformer



DSD

• DSD64 (DoP) on Coax/AES/Opt Input & Output

• Upto DSD512 On USB Input & I²S Output

PCM

• 24bits / 44.1, 48, 88.2, 96, 176.4, 192KHz On All Output

• Up to 768KHz On USB Input & Up to 384KHz on I²S Output



Digital Input

• USB2.0 Type B



External Clock Input  BNC 75Ω

• 45.1548MHz

• 49.152Mhz



Digital Output

• Coax SPDIF via RCA

• TOSLink x 1

• AES/EBU x 1

• I²S HDMI LVDS Standard

• I²S RJ45 LVCMOS Standard



AC Power Requirement: 100-240VAC, 50/60Hz (Worldwide Voltage, Manual Selector)

Fuse: T2A/250VAC. 5x20mm 2A Slow Blow

Power Consumption: ≤20W

Dimension: 220W x 250D x 44H mm (Feet +18mm)

Package Dim: 375 x 330 x 115 mm

Package Content: DDC & Power Cord. No remote control.

Weight: 3.5 Kg

Color: Black

Warranty: 12 Months
